3.5 INCH TN TFT LCD WITH RTP
3.5 inch TN tft lcd display with Resistive Touch Panel compatible with LQ035NC211
A 3.5 inch TN TFT LCD with resistive touch for industrial HMI, portable instruments and embedded controls. DS-T035SLH-01PD provides 320x240 resolution, RGB 24-bit interface and mechanical compatibility with LQ035NC211.
Model: DS-T035SLH-01PD
3.5 inDisplay Size
320x240Resolution
TN TFTLCD Type
RTPTouch Panel
320 cd/m²Luminance
PRODUCT ADVANTAGES
LQ035NC211-compatible touch display for embedded controls
Integrated resistive touch
The RTP supports reliable operation with a finger, stylus or gloved hand in industrial environments.
RGB 24-bit interface
The 54-pin RGB 24-bit interface supports integration with compatible embedded controllers and carrier boards.
LQ035NC211 compatibility
The module is designed as a compatible replacement option for applications using the LQ035NC211 mechanical format.
PRODUCT GALLERY
Module views and application highlights
Images are presented in the supplied order. The first image is the catalog cover image.
MECHANICAL DRAWING
Product dimensional specification
The supplied drawing shows the 54.48 x 84.71 mm LCM outline, 70.08 x 52.56 mm active area, 50-pin FPC and 4.47 mm RTP plus LCM thickness. Confirm the final drawing revision with DISEA before production release.
Request Drawing Confirmation
ENGINEERING SELECTION NOTES
Is DS-T035SLH-01PD the Right TFT LCD for Your Project?
Use the specification and drawing together before PCB, enclosure or sample approval.
DS-T035SLH-01PD combines a 3.5 inch TN TFT LCD with 320 x 240 resolution, RGB 24-bit, 54 pin interface and Resistive touch panel. It is a candidate for industrial HMI, instruments, medical devices and embedded controls when the outline, connector position, electrical timing and environmental limits match the host product.
- Controller and interface: HX8238D with RGB 24-bit, 54 pin; confirm initialization, pin assignment and host compatibility.
- Optical and touch target: 320 cd/m² luminance with Resistive touch panel; review ambient light, viewing direction and cover requirements.
- Environment: operating temperature -20 to 70 °C; validate the installed thermal and enclosure conditions.
- Mechanical release: request the latest controlled drawing before fixing the PCB, bezel, FPC route or connector.
START YOUR PROJECT
Need an LQ035NC211-compatible 3.5 inch touch display?
Send your application, interface requirements and volume forecast for a technical review.
